Specifications:
| Gross weight | 43g |
| Name | EDL Cable Qualcomm Chipset |
| Suitable for | Xiaomi |
Main Role of the Engineering Line:
1. Can ignore the existence of the BL lock , directly flash the phone to the depth!
2. This line is the service cable , for the system software failure to flash , as long as you can enter
the 9008 mode through the engineering line , you can repair , otherwise it is recommended to change
the font library!
How to protect the data to unlock:
1. To unlock the phone , you need to enter the REC mode and unlock it through the assistant. If the phone
cannot enter the REC mode , there is no way to use the engineering line!
How to Use:
1. The first method: Put the phone in the off state , insert the engineering line , and press and hold
the engineering line switch and the phone power button for about 5 seconds , the computer will “click” ,
the device manager will appear 9008 port. It means that you have successfully entered the deep flashing
mode , and then use the for MIUI flashing tool to flash the machine once to solve various problems!
2. The second method: When the phone is turned off , to enter Fastboot mode , click Volume Down button
and power button , then press the power button to turn off the phone. When the phone is black , press the
depth button button for 5 seconds , then release the hand , this time , device management inside the device
can recognize 9008 port , the appearance of 9008 port indicates that it has successfully entered the deep
flashing mode , and then use the for MIUI flashing machine tool to refresh the point , select the data ,
and then flash the machine. Solve various problems in one go! The whole process of the mobile phone is
in a black screen state. This is normal and you don't have to worry.
