Product Features:
The latest high speed programmer for iPhone / iPad NAND Flash EEPROM IC, Support iphone / ipad NAND Flash, Baseband /
Logic EEPROM IC, EEPROM CHIP Read Write Erase Repair function, help phone repair engineer fix the brush and boot errors
on iphone / ipad hardwares, Backup, format, one-click read and write hard disk underlying data, support new blank hard disk,
repair perfectly the 6/9/14 failure caused by iphone / ipad NAND Flash.
Support hard disk formatting, modify the bottom of the hard disk, hard disk data programming includes: SN / model / country /
color / wifi / Bluetooth / cellular / MLB supervision / fingerprint code / NSrN / battery code / LCD code/rear camera/front camera.
Solve the problem of the fake capacity of the engineering board hard disk, whether the engineering board is 64G, 128G, the
mobile phone only show 4G, the instrument can be easily solved
Support for iPhone 7 Plus / 7 / 6S Plus / 6S / 6 Plus / 5S / 5C / 5 / 4S
Support for iPad 2 (above of 2.4 version) / 3 / 4 / 5 (iPad Air) / 6 (iPad Air 2)
Support for iPad mini / mini2 / mini3 /mini4
Support for iPad Pro 9.7 / 10.5 / 12.9 / new
NAND expansion: 16GB upgrade expansion 64GB/128GN/256GB, iPad unlock
NAND repair: Repair when the hard disk chip is damaged or the hard disk serial number data is lost.
NAND replacement: bad hard disk chip on bad motherboard reprogramming again normal use
WIFI repair: 6S/6SP/7/7P/iPad Pro hard drive and wifi data match encryption, change the wifi chip first unbind hard drive data
NAND_Flash: Read, Write, Erase, Check function:
ID Test: Reading NAND ID, Model, Size ...ect information.
Read Test: print Internal partial data information
Read All: Read the full font data, and also saved to the computer
Erase Block: Erase the Part block data
Erase ALL: Erase NAND.
Write Block: Write the Part block data
Write ALL: Write NAND Boot (Font) information.
NAND Bus communication parameters
Read Test, Erase Block, Write Block
Support iPhone 4S - 6P and iPad 2/3/4/5/6/MINI1/2/3/4 NAND Flash: 32bit + 64bit
iPhone 4S-6P series are NAND structure, which includes the underlying data read and write, hard disk partition read and write,
user area read and write, formatting, full erasure, etc... used to solve iphone/ipad memory expansion, flashing error reporting,
and even engineering NAND Flash copy and other functions
E3NAND- iPhone 6S / 6SP / 7 / 7P / iPad pro 9.7/10.5/12.9/new
6S-7P series NAND is E3NAND structure, and has a PCI-E x2 interface, commonly known as a PCI-E NAND Flash. Contains
the underlying data read and write, NAND Flash partition, repair and brush machine error reporting! It can even solve the
problem of NAND on the engineering board in seconds.
SPI_FLASH:
8 foot chips, support a full range of SPI hard drives.
EEPROM:
4pin chip (EEPROM IC), widely used in mobile phones repair, same type as iPhoneX display screen photosensitive, easy to
read and write.
